1.适用于大直径的木材，直径可达1300mm。
It is used to rotary cut the big diameter wood and wood diameter can be up to 1500mm.
2.台湾DELTA变频器，法国品牌施耐德电器元件，运行稳定。
TAIWAN DELTA brand inverter and FRANCH SCHNEIDER electric components, machine runs stably.
3.整体框架由钢板和槽钢焊接而成，持久耐用。
The whole structure is welded by the Q235B steel and channel steel, it is durable.
4.旋切精度高，速度快，板面光滑。
Rotary cutting accuracy, quick speed, veneer surface smooth.
5.整机卡轴系统是液压控制，采用双卡头设计，使旋切木轴降低到了最小。
Whole machine chuck system is controlled by hydraulic station, adopt double chucks design, make the left core after peeling can reach min.
Structure: | Vertical |
Wood length: | 2000mm-2600mm |
Max. wood diameter: | 1300mm |
Remaining wood Min. diameter: | 160mm |
Veneer thickness: | 1mm-10mm |
Motor brand: | CHINA HUALI |
Peeling speed: | 10-40m/min |
Total power: | 69.6kw |
Inverter: | TAIWAN DELTA |
Voltage and frequency: | 380V, 50HZ |
Gearbox: | CHINA brand |
Pressure bar: | Electric |
Peeling knife: | HSS(high speed-steel) |
Machine weight: | about 23000KGS |
Machine dimension: | 6000*2300*2600mm |
