Features:
(1) The main frame adopts high-quality national standard steel plate to be welded at one time. Simple but strong structure, reasonable design, great rigidity, big undertaking strength.
(2) Machine models are sufficient, customers can choose according to their own requirements.
(3) Micro-computer control, high degree of automation, high reliability, convenient adjustment and long service life.
(4) The hydraulic control system adopts imported hydraulic parts. The pressurization is quick and accurate, and the working efficiency is high.
(5) It is the main equipment for producing plywood, blockboard, bamboo glue board, gorgeous board, plastic surface decorative board.
Technical parameters:
| Pressure | 500T | 500T | 800T |
| Board feeding direction | Transverse | Transverse | Transverse |
| Layer | 12 | 15 | 10 |
| Layer space | 70mm | 70mm | 100mm |
| Hot platen quantity | 13 | 16 | 11 |
| Hot platen size | 1370*2700*42mm | 1370*2700*42mm | 1370*2700*52mm |
| Hot platen inside pipeline | Two inlet and two outlet | Two inlet and two outlet | Two inlet and two outlet |
| Cylinder | Ø360mm*2pcs | Ø360mm*2pcs | Ø260mm*6pcs |
| Cylinder stroke | 840mm | 1050mm | 1050mm |
| Cylinder brand | WUXI brand and solid body | WUXI brand and solid body | WUXI brand and solid body |
| Allowed pressure | ≤25mpa | ≤25mpa | ≤25mpa |
| Flow of high pressure pump | 250x2pcs | 250x2pcs | 400x2pcs |
| Allowed pressure | 3Mpa | 3Mpa | 3Mpa |
| Motor power | 11kw*2pcs | 11kw*2pcs | 18.5kw*2pcs |
| Flow of high pressure pump | 25ml/rx1pcs | 25ml/rx1pcs | 25ml/rx1pcs |
| Allowed pressure | 25mpa | 25mpa | 25mpa |
| Motor power | 7.5kw*1pcs | 7.5kw*1pcs | 11kw*1pcs |
| Controlling methods | Automatic hydraulic stations | Automatic hydraulic stations | Automatic hydraulic stations |
| Up and down beam height | 900mm | 900mm | 1000mm |
| Middle beam | 400mm | 400mm | 400mm |
| Main steel plate thickness | 35mm | 35mm | 45mm |
| Heating medium | Thermal oil or steam | Thermal oil or steam | Thermal oil or steam |
| Total weight of this machine | 29Ton | 33Ton | 33Ton |
| Dimension | 3800x1370x3586mm | 3800x1370x3942mm | 3800x1370x3602mm |
